Description

The NostalgiTone Phaser Single brings the essence of several iconic designs into one compact circuit. Using LDRs (Light Dependent Resistors), it creates smooth transitions between phase shifts, resulting in an organic modulation tone. With precise control over Rate, Intensity, Volume, and Voice, this Phaser allows you to fine-tune your sound for maximum versatility. Reduced noise levels ensure a clean audio experience, while placing it pre-distortion in your signal chain delivers classic phasing tones that perfectly complement other effects.

• Easy Wiring: No more daunting wiring hassles! Say hello to beauty under the hood. Enjoy all-analog tones with modern features that will slip into your gig bag, ensuring you are always ready to unleash your musical magic.
• Available Components: We recognize the hurdles of component availability. Rest assured, we’ve carefully selected components for the NostalgiTone series currently available from today’s popular vendors.

Mainboard Dimensions – 2.10” x 2.12” – Perfectly sized for a 1590B or 125B enclosures.

Included with each PCB purchase. – (1) Mainboard, (1) wiring board, and (1) ribbon cable.

Video Demo below shows the Phaser from the DSOTM session.

NostalgiTone Phaser Build Document

Do not forget your LDR-LFO sets.

Order a drilled enclosure from Tayda (registration required)

• 1590B size – Drilled Enclosure Link
• 125B size (slightly larger) – Drilled Enclosure Link

Courtesy Artwork PNG suitable for Decals.

Courtesy 1590B Art PDF for Tayda submission.

Courtesy SVG file for Inkscape editing (zipped).
